AirPro Pressure Air Spray Gun ( Spray Painting )
Product Code & Goods Description

The AirPro air spray gun delivers exceptional spray performance while addressing your environmental and operator concerns - whether you’re a custom shop or a high-volume manufacturing facility. Ideal for automotive, general metal, wood, waterborne, high wear and adhesive applications.

Features:

  • Even material distribution through the spray pattern for optimum coverage
  • Improved transfer efficiency through reduced air consumption
  • Uniform air flow through reduced air consumption
  • Enhanced atomization through material-specific aircaps
  • Maximize operator comfort with lightweight design, low trigger force and ergonomic handle
  • Reduce maintenance and downtime with fewer gun parts
Quantity
add to cart Download brochure Download Manual
Technical Specifications

Maximum Air Inlet Pressure ................................................100 psi (0.7 MPa, 7 bar)

Maximum Fluid Inlet Pressure .......................................... 300 psi (2.1 MPa, 21 bar)

Maximum HVLP/Compliant Inbound Air Pressure*

HVLP** ............................................................19-30 psi (0.1-0.21 MPa, 1.3-2.1 bar)

Compliant** ....................................................29-35 psi (0.2-0.24 MPa, 2.0-2.4 bar)

Air Consumption

Conventional General Metal @ 36 psi (0.25 MPa, 2.5 bar) .........................12.6 cfm

HVLP General Metal @ 19 psi (0.13 MPa, 1.3 bar) ......................................14.9 cfm

Compliant General Metal @ 29 psi (0.2 MPa, 2.0 bar) ................................11.7 cfm

Fluid and Air Operating Temperature Range ..............................32°-109°F (0°-43°C)

Weight ............................................................................................. 410 g (14.46 oz)

Air Inlet ...................................................................................... 1/4 npsm (R1/4-19)

Fluid Inlet ................................................................................. ..3/8 npsm (R3/8-19)

Wetted Parts .................................... 303 SST, 17-4 PH SST, PEEK, acetal, UHMWPE

* Produces 10 psi (0.07 MPa, 0.7 bar) spraying pressure at aircap

** Dependent on application type
